BIXOLON SRP 350plus III Bluetooth Receipt printer

เครื่องพิมพ์ใบเสร็จความร้อน ไบโซรอน SRP 350plus III Bluetooth

Thermal Printer BIXOLON SRP 350plus III Bluetooth Slip Printer

เครื่องพิมพ์ใบเสร็จแบบไร้สาย ที่เชื่อมต่อผ่าน Bluetooth เป็นเครื่องพิมพ์ขนาด 3 นิ้วที่มีความละเอียดของหัวพิมพ์ 180dpi มีความไวในการพิมพ์ 300มม ต่อวินาที ที่มีช่องการเชื่อมต่อให้เลือกได้หลายแบบ พร้อมช่องต่อลิ้นชักเก็บเงินที่สามารถสั่งเปิดลิ้นชักผ่าน Driver ได้ โดยตัวเครื่องพิมพ์ BIXOLON SRP 350plus III สามารถเลือกการเชื่อมต่อได้ดังนี้  USB V2.0 FS + Ethernet และ USB V2-0 FS + Ethernet + Serial, Parallel, Powered USB หรือ Bluetooth V4.2 + LE รุ่นบลูทูธ (Option) รวมถึงการสั่งค่าการใช้งานผ่าน  ระบบปฏิบัติการ ™ (รับรองมาตรฐาน MFi), Android ™และ Windows ™ อีกคุณสมบัติเด่นของเครื่อง BIXOLON SRP 350plus III ตัวเครื่องยังสามารถป้องกันน้ำ ได้



*หมายเหตุ คุณสมบัติเครื่องอาจมีการเปลี่ยนได้ทั้งนี้กรุณาติดต่อทางบริษัทฯ เพื่อความถูกต้องต่อไป*



คุณสมบัติหลัก Main specification Slip Printer BIXOLON SRP 350plus III Bluetooth

Print Characteristics
Print Method
Direct Thermal
Print Speed
SRP-350plusIII: Up to 300 mm/sec
SRP-352plusIII: Up to 270 mm/sec
Print Resolution
SRP-350plusIII: 180 dpi
SRP-352plusIII: 203 dpi
Print Width
Up to 72 mm
Sensor
Paper End, Paper Near End, Cover Open

Media Characteristics
Media Type
Receipt
Media Width
80 mm
Optional 58 mm (N type)
Media Roll Diameter
Up to 83 mm
Media Thickness
0.05 ~ 0.08 mm
Supply Method
Easy Paper Loading

Physical Characteristics
Dimensions (W x D x H)
145 x 200 x 146 mm
(5.70 x 7.87 x 5.74 inch)
Weight
1.56 kg (3.43 lbs.)
Electrical
EnergyStar Certified,
External Power Adaptor 100-240V AV, 50/60Hz
Drawer Port
2 ports (via y-type adaptor
Performance Characteristics
NV Image Memory
768 Kbytes (mono)
Receive Buffer
4 Kbytes
User Define Buffer
12 Kbytes
Interface
Standard: USB V2.0 FS + Ethernet
Optional: USB V2.0 FS + Ethernet + Serial /
Parallel / WLAN¹ / Bluetooth² /
Powered USB
---------------------------------------
WLAN¹ : 802.11a/b/g/n(2.4G+5G)
Bluetooth² : V4.2 Classic / LE, Class 1,
MFi certified

Environment Characteristics
Temperature
Operating: 0 ~ 40℃ (32 ~ 104℉)
Storage: -20 ~ 60℃ (-4 ~ 140℉)
Humidity
Operating: 10 ~ 80% RH
Storage: 10 ~ 90% RH

Reliability
Thermal Print Head (TPH)
150 km
Auto Cutter
1.8 Million Cuts
Software
Emulation
BXL / POS
Driver / Utility
Windows Driver, OPOS / JPOS Driver,
Linux / Mac CUPS Driver,
Virtual COM USB / Ethernet Driver,
Utility Program
SDK / Plugin
Android / iOS / Windows SDK, Linux SDK,
Windows Runtime SDK, Xamarin SDK,
Chrome SDK, Cordova Plugin
Application
mPrint App (iOS), mPrint Server (Windows, iOS)
MDM
BIXOLON Profile Manager
- XPM™, XCM™ (Windows, Android)

Fonts / Graphics / Symbologies
Character Size
Font A: 12 x 24 Font B: 9 x 17 Font C: 9 x 24
KOR, CHN, JPN: 24 x 24
Characters Per Line
SRP-350plusIII: Font A: 42 Font B, C: 56
KOR, CHN, JPN: 21
SRP-352plusIII: Font A: 48 Font B, C: 64
KOR, CHN, JPN: 24
Character Sets
Alphanumeric: 95
Extended Graphics: 128 x 35 page
International: 32
Graphics
Supporting user-defined fonts, graphics,
formats, and logos
Barcode Symbologies
1D: Codabar, Code 39, Code 93, Code 128,
EAN-8, EAN-13, ITF, UPC-A, UPC-E
2D: Data Matrix, PDF417, QR code

Accessories
Standard
Cable-DK Gender
Optional
Splash Proof Cover, External buzzer, B-Melodist,
USB A-B Cable 1.8m, Powered USB 0.5m,
Powered USB 1.2m
