PHYSICAL CHARACTERISTICS
Dimensions with Battery (L × W × D):
23.7 × 8.0 × 4.3 cm (9.33 × 3.16 × 1.69 in)
Weight: 562 g (19 oz) with battery
Width: grip area 6.42 cm (2.53 in)
ENVIRONMENTAL
Operating Temperature:
-20°C to +60°C (-4°F to +140°F)*
Storage Temperature:
-30°C to +70°C (-22°F to +158°F)
Charging Temperature:
+5°C to +35°C (41°F to 95°F)
Relative Humidity: Non-condensing, 95%
Rain & Dust Resistance: IP67
Drop Specification: 2.4 m (8 ft) to concrete per
MIL-STD 810G; 1.8 m (6 ft) to concrete across
operating temperature range per MIL-STD
810G; 2,000 (1 m) tumbles per IEC 60068-2-32
specification
Electrostatic Discharge:
± 15 kV air discharge; ± 8 kV direct discharge
POWER
Battery Pack: 3.7 V, 5200 mAh; IEEE 1725
compliant, Li-Ion, removable, rechargeable
OPERATING SYSTEM
Microsoft® Windows® Embedded Handheld 6.5
MICROPROCESSOR
Texas Instruments 1 GHz OMAP multi-engine
processor architecture
MEMORY & STORAGE
Memory: 512 MB RAM
ROM: 1 GB Flash
Customer-accessible micro-SD slot for removable memory cards up to 32 GB
DISPLAY
• 8.9 cm (3.5 in) Transflective VGA
• 480 x 640 pixels
• 65,536 (16-bit RGB) colors
• High-durability touch screen
• LED backlight
• Ambient light sensor
STANDARD COMMUNICATIONS
USB – Full Speed 2.0 OTG©, USB – Full Speed 2.0 Client© IrDA
SOFTWARE APPLICATIONS & COMPONENTS
Device Management: Honeywell
SmartSystems™ Foundation support includes
ScanNGo provisioning for use alone or with device management software from Honeywell ISVs
Device Health Monitoring: Remote access
requires SmartSystems management option
Application Development:
Honeywell Developer Library
Imaging Solutions: Honeywell Shipment Address
Verification (SAV) and Mobile Document Imaging (MDI) are compatible, licensed and sold separately
In-Premise Clients: Optional factory pre-loaded
Honeywell Enterprise Client Pack (TE and Browser); Honeywell Browse
|
Web Browsing: Honeywell HTML5 Browser
Device Lockdown: Honeywell Launcher
DATA MANAGEMENT
Skynax® Mobile Communications
INTEGRATED RADIOS
Wireless WAN Options
Data & Voice Options
UMTS/HSUPA
• UMTS Frequencies:
800, 850, 900, 1900, 2100 MHz
• GSM/GPRS Frequencies:
850, 900, 1800, 1900 MHz
• Max Speeds (Network Dependent):
Uplink – 5.76 Mbps; Downlink – 7.2 Mbps
CDMA/EVDO Rev. A
• CDMA Frequencies: 800, 1900 MHz
• Max Speeds (Network Dependent):
Uplink – 1.8 Mbps; Downlink – 3.1 Mbps
Data Only Option
Flexible Network™
• UMTS/HSPA+ Frequencies: 800, 850,
900, 1700, 1900, 2100 MHz
• GSM/GPRS/EDGE Frequencies: 850,
900, 1800, 1900 MHz
• Max Speeds (Network Dependent):
Uplink – 5.76 Mbps; Downlink – 14.4 Mbps
• CDMA/EV-DO Frequencies:
800, 1900 MHz
• Max Speeds (Network Dependent):
Uplink – 1.8 Mbps; Downlink – 3.1 Mbps
Wireless LAN: IEEE® 802.11 a/b/g/n Dual Band WLAN
Security: Wi-Fi Certified for WPA and WPA2,
WAPI Certified
Cisco® Compatibility: CCXv4
Authentication: 802.1x
Encryption: WEP (64- or 128-bit), AES, TKIP
Wireless PAN: Integrated Bluetooth® Class II,
Version 2.1+EDR
Operating Channels: 0 to 78 (2402–2480 MHz)
Data Rates: 1, 2, 3 Mbps
GLOBAL POSITIONING SYSTEM
12-channel integrated GPS; network-independent
autonomous mode; supports assisted operation
via WAN
SENSOR TECHNOLOGY
Accelerometer: Embedded accelerometer enables
automatic or application-specific features such as
screen rotation or system suspend.
AUDIO SUPPORT
Supports VoIP / speech recognition / push-to-talk applications; front and rear speakers; rear speaker >80 dB at 40 cm (15.7 in); front receiver and front panel microphone for handset audio communication and audio recording; wireless Bluetooth headset support; wired headset support via snap-on adapter
INTEGRATED SCANNER
EA30 High Performance Motion-Tolerant 2D
Imager: white LED illumination; red laser aimer
optimized for all lighting conditions; 35-degree
downward scan angle; capable of scanning all
common 1D and 2D barcodes; 1D as small as
|
5 mil; PDF as small as 6.6 mil; data matrix as small as 7.5 mil; standard UPC codes from distances up to 33 cm (13 in)
INTEGRATED RFID READER OPTION
The CK70 is available with integrated UHF RFID reading capabilities. For more information, see the 70 Series RFID product page.
INTEGRATED CAMERA OPTION
5-megapixel auto focus color camera with LED flash
KEYPAD OPTIONS
Both keypad options feature hard keycaps with
laser-etched legends
|
