Newland HR1550 CE Barcode Scanner Wireless (1D)

เครื่องอ่านบาร์โค้ดไร้สาย นิวแลนด์  HR1550 CE (1D)

เครื่องสแกนบาร์โค้ด Wireless Newland HR1550 CE (1D)

Newland HR1550 CE Barcode Scanner เครื่องสแกนบาร์โค้ดแบบไร้สาย Newland HR1550 CE Barcode Scanner สามารถอ่านบาร์โค้ดได้ทั้ง 1D , PDF417 และ MicroPDF417 หัวอ่านบาร์โค้ด Newland HR1550 CE Barcode Scanner เป็นหัวอ่านแบบ Image Cmos ที่มีความเร็วในการอ่านบาร์โค้ด ได้ ถึง 300 สแกนต่อวินาที โดย Newland HR1550CE ได้รวมเทคโนโลยี Zigbee Wireless ทำให้การเชื่อมต่อระหว่างหัวสแกน และฐานสามารถห่างกันได้ถึง 50 เมตร นอกจากนี้ฐานของเครื่อง HR1550 CE ยังสามารถเชื่อมต่อหัวอ่านได้หลายตัวเครื่องได้ การเชื่อมต่อ ก็สามารถทำได้ง่าย ๆ ผ่านปุ่ม Match ที่แท่นวาง หรือวางหัวอ่านบนแทนวาง ได้ และแท่นวางยังสามารถค้นหาสแกนเนอร์ที่จับคู่ผ่านปุ่ม Match

Newland HR1550 CE Barcode Scanner ยังรองรับการส่งข้อมูล ได้ทั้งในโหมด Synchronous, Asynchronous และ Batch กรณีที่หัวอ่านไม่สามารถติดต่อกับตัวฐานได้ สามารถต่อเข้ากับPort RS-232 / USB เหมาะสำหรับซูเปอร์มาร์เก็ต,ห้างสรรพสินค้ามการจัดการคลังสินค้า,การค้าปลีก,ผู้จัดจำหน่ายการจัดการการผลิต,การตรวจนับสินค้าคงคลังและอื่น


ทั้งนี้ทางบริษัทได้ทำการจัดจำหน่าย สินค้าเครื่องพิมพ์บาร์โค้ด เครื่องพิมพ์บาร์โค้ด เครื่องอ่านบาร์โค้ด เครื่องพิมพ์ใบเสร็จขนาดพกพา คอมพิวเตอร์ขนาดพกพา เครื่องพิมพ์บัตร และอุปกรณ์การพิมพ์ ทั้งสติกเกอร์ม้วนสำหรับการพิมพ์บาร์โค้ด ผ้าหมึกสำหรับเครื่องพิมพ์สติกเกอร์ ที่มีคุณภาพราคาที่เหมาะสม



*หมายเหตุ คุณสมบัติเครื่องอาจมีการเปลี่ยนได้ทั้งนี้กรุณาติดต่อทางบริษัทฯ เพื่อความถูกต้องต่อไป*

คุณสมบัติอย่างย่อ Barcode Scanner Wireless Newland HR1550 CE (1D)


ระบบการอ่าน : 1D

ความเร็วในการสแกน : 300 scans per second

ระยะห่างจากตัว ฐานได้ ไกล : ≥ 50m ในที่โล่ง

หัวอ่าน : Image Sensor CCD 2500

ระยะการอ่าน EAN13 (13mil)    31.5-465.5mm.

กันกระแทก : 1.5m

การเชื่อมต่อ : USB  (Option  RS232)

 คุณสมบัติหลัก Main specification Newland Wireless Barcode Scanner HR1550 CE (1D)

Performance

Image Sensor        CCD 2500

Illumination Red LED (620nm)

Depth of Field EAN13 (13mil)    31.5-465.5mm

Minimal Print Contrast    25%

Scan Angle Roll     30°

Scan Angle Pitch   ±55°

Scan Angle Skew  ±75°

Field of View Horizontal  42°

Scan Modes  Manual Mode, Auto Mode, Blink Mode, Sense Mode, Continuous Mode, Delayed Sense Mode

Scan Rate    300 scans per second

Data capture

1D      Code 128, EAN-13, EAN-8, Code39, UPC-A, UPC-E, Codabar,Interleaved 2 of 5, ISBN, Code 93, UCC/EAN-128, GS1 Databar,PDF417 (max. 255 bytes), MicroPDF417 (max. 255 bytes), etc.



Physical

Dimensions (mm)  Scanner 113.5×73×159mm Cradle 195×82.5×47mm

Weight         Scanner 210g (including battery) Cradle 150g

Material        PC,ABS

Buttons        Trigger

Interfaces     RS-232, USB

Battery Type          2200mAh lithium-ion battery

Expected Battery Life      >17 hours

Expected Charge Time    3.5 hours|3.5 hours

Notifications          Beep, LED indicator

Input Voltage         5VDC±5%

Power Supply Input         DC5V, 1.5A

Power Supply Output      AC100~240V, 50~60Hz



Environmental

Operating Temperature   -10°C to 50°C (14°F to 122°F)

Storage Temperature       -20℃ to 60℃ (-4°F to 140°F)

Humidity      5%~95% (non-condensing)

Electro Static Discharge (ESD)  ±8 KV (contact discharge); ±12 KV (air discharge)

Drop  1.5m

Sealing        IP54



Wireless

Communication Distance          ≥ 50m

Communication Modes   Synchronous, asynchronous and batch modes



Accessories

Optional      RS232 Cable

Standard      USB Cable,Adapter



Certifications

Certifications         FCC Part15 Class B,CE EMC Class B,KC
