Zebra CS3070 CS3000 Barcode Scanner ราคาพิเศษ

Zebra CS3070 CS3000 Barcode Scanner ราคาพิเศษ

เครื่องสแกนบาร์โค้ด Bluetooth Zebra CS3070 CS3000 (1D)

Scanner Barcode Zebra CS3070 CS3000 เครื่องสแกนบาร์โค้ดแบบบาร์แท่ง 1D Laser Scanner รองรับการเชื่อมต่อแบบ Bluetooth Class 2 ระยะ 10 เมตรในแนวสัญญาณ

CS3070 CS3000  เครื่องสแกนบาร์โค้ดขนาดเล็กแบบไร้สาย เหมาะสำหรับพกพาทำงานนอกสถานที่ เป็นอีกหนึ่งตัวช่วยในการทำงานนอกสถานที่ เครื่องสแกนบาร์โค้ด Zebra CS3070 CS3000  ตัวเครื่องมีแบตเตอรี่ 780 mAh Lithium ion ชาร์ไฟผ่านสาย USB และ สามารถบันทึกค่าลงในตัวสแกน Zebra CS3070 ที่มีหน่วยความจำ 512MB Flash  8500 สแกนกรณีเชื่อมต่อ แบบ Bluetooth สามารถใช้งานได้ 12 ชั่วโมง การเชื่อมต่อเพื่อดึงข้อมูล ผ่าน PORT USB ตัวเครื่องรองรับการเชื่อมต่อ IPAD iPhone Android

Scanner Barcode Zebra CS3000 CS3070 ตัวเครื่องอ่านสามารถเชื่อมต่อ กับ Bluetooth ผ่านระบบ Realtime ไปยังแอปพลิเคชั่น ไร้สายไปยังสมาร์ทโฟน แล็ปท๊อป และอื่น ๆ ด้วย เครื่อง Scanner Barcode Zebra CS3070 CS3000 ตัวเครื่องมีอินเทอร์เฟซ 2 ปุ่ม และด้วยตัวเครื่อง มี SE955 scan engine  ในตัวที่มอบคุณภาพและความน่าเชื่อถือในการสแกนที่มีชื่อเสียงระดับโลก ในราคาที่เหมาะสม



*หมายเหตุ คุณสมบัติเครื่องอาจมีการเปลี่ยนได้ทั้งนี้กรุณาติดต่อทางบริษัทฯ เพื่อความถูกต้องต่อไป*

คุณสมบัติอย่างย่อ Barcode Scanner Bluetooth Zebra CS3070, CS3000 (1D)


ระบบการอ่าน : 1D

ระยะห่างจากตัว ฐานได้ ไกล : 10 M ในที่โล่ง

หัวอ่าน : Laser

กันกระแทก : 4 ft./1.21 m drop

การเชื่อมต่อ : USB  (Option  RS232)

คุณสมบัติหลัก Main specification Zebra Bluetooth Zebra CS3070, CS3000 (1D)

PHYSICAL CHARACTERISTICS
Dimensions : 3.41 in. L x 1.95 in. W x .87 in. H 8.65 cm L x 4.95 cm W x 2.2 cm H
Weight With batteries: 2.45 oz./70 gm
Scan Engine : SE955 laser, single line
Memory : 512MB Flash
Memory Capacity : Over 1 million barcodes (UPC with time date stamp)
LEDs : Scan LED (Green, Red, and Amber) and Bluetooth® LED (Blue)
Buttons : Scan, remove scan (batch mode only), enable Bluetooth (RFscanners only)

OPERATING MODES
Batch : Scans recorded with optional time/date stamp
Open Bluetooth : Real time wireless data transmission

BATTERY
Battery : 780 mAh Lithium ion
Charge Time : 3 hours
Battery Life : Batch - 24 hours use or 8,500scans (6 scans per minute on full charge)Standby - 3 months Bluetooth - 12 hours use or 4,250 scans (6 scans per minute on full charge)
Power Consumption : 5V, 500mA max while charging

PERFORMANCE CHARACTERISTICS
Decode Capability : 1-D symbologies
Interfaces Supported USB (Mini jack): CS3000 and CS3070,Bluetooth: CS3070
Real Time Clock : A date/time stamp can be recorded with each bar code scanned (Batch mode operation only)
Batch Communication :USB 2.0

BLUETOOTH
Bluetooth Radio : Bluetooth, Class 2, Version 2.1 + Enhanced Data Rate (EDR)
Bluetooth Range : 30 ft./10 m
Bluetooth Profiles : HID keyboard wedge and Serial Port Profile (SPP)

USER ENVIRONMENT
Drop Specification : 4 ft./1.21 m drop to tiled linoleum over concrete, 6 drops per 6 sides,across the operating temperature range
Tumble Specification : 250 cycles @ 1.64 ft./0.5 m (500 drops)
Operating Temperature : 32° to 104° F /0° to 40° C
Storage Temperature : -40° to 158° F /-40° to 70°C
Humidity : 10 to 95% noncondensing
Ambient Lighting Tolerance : Tolerant to typical artificial indoor and natural outdoor (direct sunlight) lighting conditions. Fluorescent,Incandescent, Mercury Vapor,Sodium Vapor, LED : 450 Ft Candles (4,844 Lux) Sunlight:8000 Ft Candles (86,111 Lux)

REGULATORY
Laser Safety : EN 60825-1, IEC 60825-1, 21CFR1040.10
EMC
CS3000: FCC Part 15 Class B,ICES 003 Class B, EN 55022, EN 55024
CS3070: FCC Part 15 Class B,ICES 003 Class B, EN 55022, EN 55024, EN 301 489-1, EN 301 489 -17
Radio: CS3070: EN 300 328
Electrical Safety : UL 60950-1, C22.2 No. 60950-1,EN 60950-1,
IEC 0950-1
Environmental : RoHS Directive 2002/95/EEC

DECODE RANGE
4 mil: 0.90 – 4.90 in. / 2.3 – 12.4 cm
5 mil: 1.20 – 7.40 in. / 3.0 – 18.8 cm
7.5 mil: 1.60 – 12.40 in. / 4.1 - 31.5 cm
10 mil: 1.60 – 17.40 in. / 4.1 – 44.2 cm
100% UPC: 1.60 – 23.40 in. / 4.1 – 59.4 cm
15 mil: 1.60 – 24.40 in. / 4.1 – 62.0 cm
20 mil: 1.90 – 25.40 in. / 4.8 – 64.5 cm
40 mil: *- 27.40 in. / * - 69.6 cm
55 mil: *- 31.40 in. / * - 79.8 cm
