Zebra ZT411 ZT421 Barcode Printer ราคาพิเศษ

เครื่องพิมพ์บาร์โค้ดสติกเกอร์ ซีบร้า ZT411 ZT421

เครื่องพิมพ์ Zebra ZT411 ZT421 Barcode Sticker Printer

 Zebra ZT411 และ Zebra ZT421 เครื่องพิมพ์บาร์โค้ดเกรดอุตสาหกรรม Industrial Barcode Printer ถูกสร้างขึ้นด้วยโครงโลหะทั้งหมดและประตูสองพับเครื่องพิมพ์เหล่านี้มีความทนทานและช่วยให้เข้าถึงได้ง่าย หน้าจอสัมผัสสีเต็มขนาด 4.3 นิ้วพร้อม Interface ที่ใช้งานง่ายทำให้ใช้งานง่ายและแสดงการแจ้งเตือนสถานะเครื่องพิมพ์รหัสสี กำหนดค่าเครื่องพิมพ์ในแบบของคุณด้วยเทคโนโลยีขั้นสูงพร้อมกับช่องสื่อสารแบบเปิดสองช่อง เครื่องพิมพ์เหล่านี้ช่วยให้การทำงานที่สำคัญของคุณทำงานได้อย่างมีประสิทธิภาพในปัจจุบันและให้ความยืดหยุ่นในการเพิ่มคุณสมบัติต่างๆในอนาคตตามที่คุณต้องการ มีให้เลือกสามความละเอียดการพิมพ์และความกว้างการพิมพ์สองความกว้าง Zebra ZT411 และ Zebra ZT421 ซีรี่ส์ตอบสนองการใช้งานที่หลากหลาย ง่ายต่อการผสานรวมและจัดการกับชุดแอพพลิเคชั่น Print DNA ของ Zebra ยูทิลิตี้และเครื่องมือสำหรับนักพัฒนาทั้งหมดขับเคลื่อนโดย Link-OS®

Zebra ZT411 และ Zebra ZT421 Industrial Barcode Printer ออกแบบมาเพื่อตอบสนองความต้องการทางธุรกิจในปัจจุบันและอนาคต  Zebra ZT411 Barcode printer และ Zebra ZT421 Barcode Printer  เครื่องพิมพ์บาร์โค้ด มอบความก้าวหน้าในด้านความเร็วในการพิมพ์ตัวเลือกการเชื่อมต่อและเครื่องมือการจัดการและการสนับสนุน ตัวเลือก Option ที่สามารถติดตั้งได้จากโรงงานหรือภาคสนามรวมถึง RFID และการจัดการสื่อช่วยให้คุณสามารถปรับแต่งเครื่องพิมพ์ของคุณให้ตรงกับความต้องการของคุณในปัจจุบันและอนาคต และสถาปัตยกรรมแบบเปิดช่วยให้เครื่องพิมพ์เหล่านี้ก้าวไปพร้อมกับเทคโนโลยี

Zebra ZT411 และ Zebra ZT421 มีการเชื่อมต่อมาตรฐาน USB, Serial, Ethernet, โฮสต์ USB คู่และตัวเลือกการเชื่อมต่อ Bluetooth; และช่องเสียบสื่อแบบเปิดสองช่องช่วยให้คุณสามารถเพิ่มการ์ดอินเตอร์เฟส Parallel, Ethernet, แอปพลิเคชันและอื่น ๆ เพิ่มตัวเลือกการเข้ารหัส RFID ที่ติดตั้งจากโรงงานหรือภาคสนามได้อย่างง่ายดายสำหรับแท็ก UHF RFID สำหรับวัตถุประสงค์ทั่วไปหรือแท็กบนโลหะที่หนาขึ้น ตัวเลือกการจัดการสื่อที่ผู้ใช้ปลายทางสามารถติดตั้งได้ช่วยให้คุณปรับแต่งเครื่องพิมพ์ของคุณให้ตรงกับความต้องการทางธุรกิจในปัจจุบันและอนาคตของคุณ

Zebra ZT411 และ Zebra ZT421 ยังมีทั้งภาษาโปรแกรม EPL2 และ ZPL II อันทรงพลังทำให้ง่ายต่อการรวมเข้ากับเครื่องพิมพ์ Zebra อื่น ๆ ตัวเลือกเครื่องปอก / เครื่องจ่ายขยายความอเนกประสงค์ของเครื่องพิมพ์ Zebra ZT411 และ Zebra ZT421 เพื่อตอบสนองการใช้งานที่หลากหลายยิ่งขึ้นตัวเครื่องรองรับการพิมพ์สติกเกอร์ ผ่านผ้าหมึก (Thermal Transfer) และ กระดาษความร้อน (Direct Thermal) มีไฟบอกสถานะ ตัวเครื่องพิมพ์มีคุณสมบัติรองรับสติกเกอร์แบบ Gap และ Black Mark ผ่าน Sensor ของตัวเครื่องๆ Zebra รองรับการเชื่อมต่อสำหรับการพิมพ์ด้านหลังเครื่องผ่าน  USB 2.0, high-speed, RS-232 Serial, 10/100 Ethernet, Bluetooth 4.1, Dual USB Host

 ทั้งนี้เพื่อให้ง่ายต่อการ งานพิมพ์ ออกแบบ และสะดวกต่อการใช้งาน ตัวเครื่องมาพร้อมกับโปรแกรม Zebra design lesiy[ออกแบบงานพิมพ์ สามารถพิมพ์ได้ทั้ง  1D, 2D, code128, Ean13, Ean8, UPC, Code 39, code93, GS1 DataMatrix, Maxicode, QR Code และโค้ดอื่นๆ  รองรับระบบปฏิบัติการ Linux, MAC X.10, Mircosoft SQL,SAP, Oracle, WHQL 8.1, Windows, SQL Server ตัวเครื่องยังมีความพิเศษกว่าเครื่องพิมพ์รุ่นอื่นๆ ตรงที่สามารถมองเห็นสติกเกอร์และผ้าหมึก (Ribbon) ได้ในขณะใช้งาน สามารถใช้กับกระดาษสติกเกอร์ กึ่งมัน กึ่งด้าน, กระดาษความร้อน (Thermal Paper)  ,PVC, UPO,PP, ฟอยล์ เหมาะสำหรับหน่วยงานราชการ ธุรกิจเอสเอ็มอี และธุรกิจขนาดเล็ก-ใหญ่ในภาคอุตสาหกรรมต่างๆ ที่ต้องการพิมพ์บาร์โค้ดหรือสติกเกอร์สำหรับติดตัวสินค้าหรือสินทรัพย์ โดยทางบริษัทได้ทำการจัดจำหน่าย สินค้าเครื่องพิมพ์บาร์โค้ด และอุปกรณ์การพิมพ์ ที่มีคุณภาพราคาที่เหมาะสม

นอกจากนี้ตัวเครื่อง Zebra ZT411 และ Zebra ZT421 สามารถเพิ่มฟังก์ชันพิเศษ ให้สามารถตัดกระดาษอัตโนมัติ(Cutter)



*หมายเหตุ คุณสมบัติเครื่องอาจมีการเปลี่ยนได้ทั้งนี้กรุณาติดต่อทางบริษัทฯ เพื่อความถูกต้องต่อไป*

คุณสมบัติเบื้องต้น Zebra ZT411 Zebra ZT421

Zebra ZT411 ZT421  Barcode Printer
เครื่องพิมพ์บาร์โค้ด ซีบร้า ZT411 ZT421
Zebra ZT411 and Zebra ZT421 Industrial Barcode printers keep critical operations moving. Featuring advanced technology- a large color display and versatile connectivity options- this printer take performance to a new level and are adaptable for your evolving needs. Zebra ZT411 and Zebra ZT421 Intuitive to integrate and operate, they feature Zebra's Print DNA software powered by Link-OS to deliver unparalleled intelligence and innovation for exceptional performance and simplified remote manageability. Zebra ZT411 and Zebra ZT421 available in three print resolutions, they are ideal for a wide range of applications. Field installable options such as media handling and RFID encoder options to print and encode RFID labels for metal asset tracking.
ความละเอียดในการพิมพ์ : 203 dpi (8 dots/mm)  Zebra ZT41142 T0P0000Z
                               optional : 300 dpi (12 dots/mm)
                               optional for ZT411 only : 600 dpi (24 dots/mm)
หน่วยความจำ : 512 MB Flash, 256 MB RAM
ความเร็วในการพิมพ์สูงสุด : 14 ips (356 mm)/sec ZT411 12 ips (305 mm)/sec ZT412
หน้ากว้างในการพิมพ์  : 4.09"/104 mm ZT411  6.6"/168 mm ZT412
ความยาวในการพิมพ์ : 203 dpi; 157"/3988 mm
                         300 dpi;73"/1854 mm  600 dpi; 39"/991 mm,
การเชื่อมต่อ : USB 2.0, RS-232 serial, Bluetooth 4.1, Dual USB host
Standard length : 450 M (1476 ft.) Ribbon



 คุณสมบัติหลัก Main specification Zebra ZT411 Zebra ZT421

 Standard Features
  • Print Methods: Thermal transfer and direct thermal printing
  • Construction: Metal frame and bi-fold metal media cover with enlarged clear viewing window
  • Side-loading supplies path for simplified media and ribbon loading
  • Thin film printhead with E3™ Element Energy™ Equalizer for superior print quality
  • Communications: USB 2.0, high-speed, RS-232 Serial, 10/100 Ethernet, Bluetooth 4.1, Dual USB Host
  • 4.3-inch color touch display with intuitive menu for quick operation and settings management
  • Bi-colored status LEDs for quick printer status
  • ENERGY STAR qualified

Physical Characteristics

Dimensions (closed)
ZT411: 19.5 in. L x 10.6 in. W x 12.75 in. H 495 mm L x 269 mm W x 324 mm H
ZT421: 19.5 in. L x 13.25 in. W x 12.75 H495 mm L x 336 mm W x 324 mm H

Weight
ZT411: 36 lbs./16.33 kg
ZT421: 40 lbs./18.14 kg

Printer Specifications

Resolution
203 dpi/8 dots per mm

300 dpi/12 dots per mm (optional)

600 dpi/24 dots per mm (optional for ZT411 only)

Memory
256 MB SDRAM memory

512 MB on-board linear Flash memory

Maximum Print Width

  • ZT411: 4.09 in./104 mm
  • ZT421: 6.6 in./168 mm

Maximum Print Speed

  • ZT411: 14 ips/356 mm per second
  • ZT421: 12 ips/305 mm per second

Media Sensors
Adjustable dual media sensors: transmissive and reflective

Print Length
ZT411

  • 203 dpi: 157 in./3988 mm
  • 300 dpi: 73 in./1854 mm
  • 600 dpi: 39 in./991 mm

ZT421

  • 203 dpi: 102 in./2591 mm
  • 300 dpi: 45 in./1143 mm

Media Characteristics

Maximum Media Width
ZT411

  • 1.00 in./25.4 mm to 4.5 in./114 mm tear/cutter
  • 1.00 in./25.4 mm to 4.25 in./108 mm peel/rewind

ZT421

  • 2.00 in./51 mm to 7.0 in./178 mm tear/cutter
  • 2.00 in./51 mm to 6.75 in./171 mm peel/rewind



Maximum Media Roll Size  : 8.0 in./203 mm O.D. on a 3 in./76 mm I.D. core

Thickness           0.0023 in./0.058 mm to 0.010 in./0.25 mm

Media Types      Continuous, die-cut, notch, black-mark

Ribbon Characteristics

Standard Length             1476 ft./450 M

Width

  • ZT411: 2.00 in./51 mm to 4.33 in./110 mm
  • ZT421: 2.00 in./51 mm to 6.85 in./174 mm

Core      1.0 in./25 mm I.D.

Environmental

Operating Temperature Thermal transfer: 40º F to 104º F/5º C to 40º C Direct thermal: 32º F to 104º F/0º C to 40º C

Storage/Transportation Temperature   -40º F to 140º F/-40º C to 60º C

Operating Humidity       20% to 85% non-condensing

Storage Humidity           5% to 85% non-condensing

Firmware

ZBI 2.0™ — Optional powerful programming language that lets printers run stand-alone applications, connect to peripherals, and much more.
ZPL and ZPL II® — Zebra Programming Language provides sophisticated label formatting and printer control and is compatible with all Zebra printers.
EPL and EPL2™— Eltron® Programming Language with Line Mode simplifies label formatting and enables format compatibility with legacy applications. (EPL available on 203 dpi models only.)
Electrical   Auto-detectable (PFC Compliant) 100-240VAC, 50-60Hz, ENERGY STAR qualified

Options and Accessories

Communication              Two open communication slots to add internal cards for:

  • Dual band 802.11ac Wi-Fi and Bluetooth
  • Parallel (bi-directional interface)
  • 10/100 Ethernet
  • Applicator interface

Media Handling

  • Rewind: Internally rewinds a full roll of printed labels on 3” core, or peels and rewinds liner (factory installed only)
  • Peel: Front-mount, passive peel option
  • Peel: Liner take-up — additional full-roll liner take-up spindle accommodates standard printer base
  • Cutter: Front-mount guillotine cutter and catch tray
  • 1 in. I.D. Core media supply hanger (ZT411 only)
  • Ink-side in ribbon supply (ZT411 only)

RFID

  • Supports tags compatible with: UHF EPC Gen 2 V2, ISO/IEC 18000-63 and RAIN RFID protocols
  • Integrated RFID system is user-upgradable in the field and available on both 4 in. and 6 in. models
  • Adaptive Encoding Technology automatically selects optimum encode settings
  • Field installable on-metal RFID kit available*

Keyboard Display Unit   ZKDU™ keyboard display units for stand-alone printing applications

Fonts and Graphics

  • 16 resident expandable ZPL II bitmap and two resident scalable ZPL fonts Asian and other international scalable and smooth bitmapped fonts Unicode™: For multi-language printing
  • Downloadable objects include graphics, scalable and bitmap fonts, label templates and formats
  • IBM Code Page 850 international character sets are available in the fonts A, B, C, D, E, F, G and 0 through software control
  • Code Page 1250, 1252, 1253, 1254, 1255 Support with font 0
  • 64 MB user-available non-volatile memory storage for downloadable objects
  • 8 MB user-available SDRAM
