POWERSCAN9600SERIES
TECHNICALSPECIFICATIONS

WIRELESS COMMUNICATIONS
PowerScan PM9600 :
Datalogic STAR Cordless System
Radio Frequency: 433 MHz; 910 MHz;
Effective Radiated Power: 433 MHz: < 10 mW;
910 MHz: < 50 mW; Point-to-Point/Multi-Point Configuration;
Max. Readers per Radio Receiver: 16; Two Way Communications.
Radio Range (Open Air): 433 MHz: 150 m / 492 ft
low speed; 100 m / 328 ft high speed
910 MHz: 230 m / 754 ft low speed;
frequency hopping; 180 m / 590 ft high speed

PowerScan PBT9600 :
Bluetooth Wireless Technology
Radio Frequency: 2.4 GHz; Profiles: SPP (Serial Port Profile) and HID (Human Interface Device); Protocol: Bluetooth 5.0 Certified. Class 1, Class 2 and Class 3; Radio Range (Open Air): 100.0 m / 328.0 ft; Range distances are measured using the base station. Range with connection to other Bluetooth peripherals. Security: Data Encryption; Scanner Authentication

DECODING CAPABILITY
1D / Linear Codes  : Auto discriminates all standard 1D codes including GS1 DataBar™ linear codes.
2D Codes :  Aztec Code; China Han Xin Code; Data Matrix; MaxiCode; Micro QR Code; QR Code; Dot Code
Postal Codes  : Australian Post; British Post; China Post; IMB; Japanese Post; KIX Post; Planet Code; Postnet; Royal Mail Code (RM4SCC)
Stacked Codes :  EAN/JAN Composites; GS1 DataBar Composites; GS1 DataBar Expanded Stacked; GS1 DataBar Stacked; GS1 DataBar Stacked Omnidirectional; MacroPDF; MicroPDF417; PDF417; UPC A/E Composites
Digital Watermarking : Digimarc Barcodes (HP and DC models)

ELECTRICAL
Current :
Corded models: Operating (Typical):
SR: 200mA @ 5V; 120mA @ 12V. HP/DC: 280mA @ 5V / 140mA
* 12V. Standby/Idle (Typical): 187mA @ 5V / 92mA @ 12V. Cordless models: Operating 480 mA @ 3.7 V. Charging (Typical) < 15 W.
Cradle BC96xx only: 150 mA @ 5 V (Operative)
Input Voltage :
Corded models: 5 - 30 VDC ± 5%
Cordless models: Host powered: 5V DC ± 5% or 10 - 30 VDC
External power supply: 10 - 30 VDC ± 5%
Battery :
Battery Type: Lithium-Ion: 3350 mAh
Charge time @ 12 VDC: 2.5 hours to charge up to 95%,
3.2 hours to charge 100%, External Power.
Reads per charge: 80,000

ENVIRONMENTAL
Ambient Light : 0 - 100,000 lux
Drop Resistance :
Withstands 50 drops from 2.5 m / 8.2 ft @ 20 °C / 68 °F;
Withstands 50 drops from 2.0 m / 6.6 ft @ -20 °C / -4 °
Trigger Resistance : Withstands 10 million hits
ESD Protection (Air Discharge): 20 kV
Humidity (Non-Condensing) : 0 - 95%
Particulate and Water Sealing : P67 and IP65; Cradle IP65 (specific models)
Temperature
Operating: -20 to 50 °C / -4 to 122 °F
Storage/Transport: -40 to 70 °C / -40 to 158 °F
Charging: 0 to 40 °C / 32 to 104 °F nominal; 0 to 35 °C / 32 to 95 °F ideal

INTERFACES
Interfaces : RS-232 / USB / Ethernet and Industrial Protocols

PHYSICAL CHARACTERISTICS
Colors Available : Yellow/Black
Dimensions H x L x W 1 : 9.8 x 14.0 x 7.9 cm / 7.8 x 5.5 x 3.1 in
Display : PM9600-D/DK. 1.8’’ OLED graphic display; Font Dimensions: User selectable.
Keyboard : PM9600-D: 4 Keys, PM9600-DK: 16 Keys; Configurable
Weight
PD9630: 318 g / 11.2 oz, PBT9600: 415 g / 14.6 oz,
PM9600: 425 g / 15.0 oz, PM9600-D: 445 g / 15.7 oz,
PM9600-DK: 455 g / 16.0 oz

READING PERFORMANCE
Imager Sensor  : 1280 x 800 pixels
Light Source :  Aiming: 630 - 680 nm VLD Illumination: White LED reading light
Print Contrast Ratio (Minimum) : 15%
Reading Angle :  Pitch: +/- 52°; Roll (Tilt): 360°; Skew (Yaw): +/- 52°
Field of View :  SR and HP: 38° H, 24° V
Reading Indicators :  Beeper (Adjustable Tone and Volume); Datalogic’s 3GL™ (Three Green Lights) technology for good-read feedback; Datalogic ‘Green Spot’; Dual Good Read LEDs; Vibration.
Resolution (Maximum)  : SR/DC: 1D Codes: 3 mil; 2D Codes: 6 mil HP: 1D Codes: 2.5 mil; 2D Codes: 4 mil

READING RANGES
Typical Depth of Field : Minimum distance determined by symbol length and scan angle. Printing resolution, contrast, and ambient light dependent.

SR Models
Code 128
5 mils: 6.4 to 30.9 cm / 2.5 to 12.2 in
20 mils: 4 to 103.7 cm / 1.6 to 40.8 in
40 mils: 5.5 to 175 cm / 2.2 to 68.9 in
EAN/UPC 13 mils: 4 to 67.5 cm / 1.5 to 26.5 in
DataMatrix 10 mils: 6 to 30 cm / 2.5 to 11.8 in

HP Models
Code 128
2.5 mils: 6.3 to 11.5 cm / 2.5 to 4.5 in
5 mils: 3.8 to 41 cm / 1.5 to 16.1 in
40 mils: 5.5 to 242.9 cm / 2.1 to 95.6 in
EAN/UPC 13 mils: 4 to 120 cm / 1.5 to 40.2 in
PDF417 10 mils: 0.5 to 46.1 cm / 0.2 to 18.1 in
DataMatrix 10 mils: 4.2 to 32 cm /1.6 to 12.6 in

SAFETY & REGULATORY
Agency Approvals :
The product meets necessary safety and regulatory approvals for its intended use.
The Regulatory Addendum for this product can be referred to for a complete list of certifications.
Environmental Compliance : Complies to China RoHS; Complies to EU RoHS; Complies to R.E.A.C.H.
Laser Classification : Caution Laser Radiation - Do not stare into beam CDRH Class II; IEC 60825 Class 2
LED Classification : IEC 62471 LED Class: Exempt

UTILITIES
Datalogic Aladdin™ : Datalogic Aladdin configuration program is available for download at no charge.
OPOS / JavaPOS : OPOS and JavaPOS Utilities are available for download at no charge.
