TECHNICAL SPECIFICATIONS
DECODING CAPABILITY
1D / Linear Codes Auto discriminates all standard 1D codes including GS1
DataBar™ linear codes.
2D Codes Aztec Code; China Han Xin Code; Data Matrix; MaxiCode;
Micro QR Code; QR Codee; Dot code
Postal Codes
Australian Post; China Post; IMB; Japanese Post; KIX
Post; Planet Code; Portuguese Post; Postnet; Royal Mail
Code (RM4SCC); Swedish Post
Digital Watermarking Digimarc Barcodes (PD9630-HP and PD9630-DC)

ELECTRICAL
Current
Operating (Typical):
PD9630-SR: 200mA @ 5V; 120mA @ 12V
PD9630-HP/ PD9630-DC: 280mA @ 5V / 140mA @ 12V
Standby/Idle (Typical): 187mA @ 5V / 92mA @ 12V
Input Voltage 5 - 30 VDC ± 5%

ENVIRONMENTAL
Ambient Light 0 - 100,000 lux
Drop Resistance
Withstands 50 drops from 2.5 m / 8.2 ft @ 20 °C / 68 °F;
Withstands 50 drops from 2.0 m / 6.6 ft @ -20 °C / -4 °F
Tumble 5,000 @ 1 m / 3.3 ft
Trigger Resistance Withstands 10 million hits
ESD Protection (Air Discharge) 20 kV
Humidity (Non-Condensing) 0 - 95%
Particulate and Water Sealing IP67 and IP65
Temperature Operating: -20 to 50 °C / -4 to 122 °F
Storage/Transport: -40 to 70 °C / -40 to 158 °F

INTERFACES
Interfaces RS-232 / USB

PHYSICAL CHARACTERISTICS
Colors Available Yellow/Black
Dimensions H x L x W 19.0 x 14.0 x 7.9 cm / 7.5 x 5.5 x 3.1 in
Weight 318.0 g / 11.2 oz

READING PERFORMANCE
Imager Sensor
PD9630-SR/HP: 1280 x 800
PD9630-DC: 1280 x 800 color sensor
Light Source
Aiming: 630 - 680 nm VLD
Illumination: White LED reading light
Print Contrast Ratio (Minimum) 15%
Reading Angle Pitch: +/- 52°; Roll (Tilt): 360°; Skew (Yaw): +/- 52°
Field Of View
SR and HP: 38° H, 24° V
DC: 50° H, 33° V
Reading Indicators
Beeper (Adjustable Tone and Volume); Datalogic’s 3GL™ (Three Green Lights) technology for good-read feedback; Datalogic ‘Green Spot’ on the Code; Dual Good Read LEDs; Vibration.
Resolution (Maximum) PD9630-SR/PD9630-DC: 1D Codes: 3 mil; 2D Codes: 6 mil PD9630-HP: 1D Codes: 2.5 mil; 2D Codes: 4 mil

DECODING CAPABILITY
Typical Depth of Field
Minimum distance determined by symbol length and scan angle. Printing resolution, contrast, and ambient light dependent.

SAFETY & REGULATORY
Agency Approvals
The product meets necessary safety and regulatory approvals for its intended use. The Regulatory Addendum for this product can be referred to for a complete list of certifications.
Environmental Compliance
Complies to China RoHS; Complies to EU RoHS;
Complies to R.E.A.C.H.
Laser Classification Caution Laser Radiation - Do not stare into beam CDRH Class II; IEC 60825 Class 2
LED Classification IEC 62471 LED Class: Exempt

UTILITIES
Datalogic Aladdin™ Datalogic Aladdin configuration program is available for download at no charge.
OPOS / JavaPOS OPOS and JavaPOS Utilities are available for download
at no charge.
Remote Host Download Available on request
