MECHANICAL
Dimensions:
206 mm L x 78 mm W x 27mm H (8.11 in x 3.07 in x 1.06 in)
Weight: 440g (0.97lbs)
Display Size: Corning® Gorilla® Glass 5,4 inch
Resolution: 480 x 800
Backlight: LED
Touchscreen: Multi-touch capacitive (CTP),GFF
Keypad: Alpha Numeric (47 key), Function Numeric (38 key), plus two programmable side scanning keys
Universal Dock Platform: Compatible for power charging

ENVIRONMENTAL
Operating Temperature: -20°C to +50°C (-4°F to +122°F)
Storage Temperature: -30°C to +70°C (-22°F to 158°F)
Humidity: 5% to 95% (non-condensing)
Drop: Multiple 1.8 m (6 ft) drop to concrete per MIL-STD-810H crossing temperature (-10°C to +50°C/ 14°F to +122°F)
Vibration: MIL-STD-810H, Method 514.6, Procedure I
Tumble: 3000 1.0m (3.3 ft) per IEC 60068-2-32 specification
Environmental Sealing: IP65
Electrostatic Discharge (ESD): ±8 kV direct; ±15 kV air

SYSTEM ARCHITECTURE
Processor: Qualcomm 4490 octa-core: 2.4 GHz
Memory: 4 GB RAM/64 GB Flash1; 8 GB RAM/128 GB Flash
Operating System: Android 14, and upgradeable to Android 18
Storage Expansion: MicroSD (standard supports up to 2 TB)
Rear Camera: 13-megapixel color camera
PC Interface: USB 3.1 with Type-C interface
Interface Ports: 2 PIN bottom connection
Battery: Li-Ion, 7,000 mAh, 3.6 V, removable, hot swappable
Real-Time Clock (RTC): 5 min back up
Charging: Quick Charge 3.0 support, 3.5 hours to be fully charged
Battery Runtime: more than 28hours 2
Scan Engine: Honeywell Flex RangeTM XLR, Honeywell S0703 Slim Imager (1D/2D barcode symbologies)
SIM Card: 1 eSIM and 1 nano SIM
Application Software: Honeywell Mobility
Edge Utilities and Demos

LED
Battery Status Indicator: red/green/amber
Scan Indication: red/green
Sensors: 3-axes accelerometer, 3-axes gyroscope sensor, compass, hall
Localization & Language: Worldwide English

WIRELESS CONNECTIVITY
WLAN (Wi-Fi Alliance certified):
IEEE 802.11 a/b/g/n/ac/ax (2.4GHz, 5GHz,6GHz3)
Additional WLAN Features: 802.11 d/e/h/i/k/r/v/w/u, 2X2 MU-MIMO
WLAN Security: OPEN, WEP, WPA/WPA2 (Personal and Enterprise WPA2), WPA3 (OWE, SAE, Enterprise)
WLAN Supported EAP: TLS, PEAP, TTLS, PWD, LEAP, CCX compliant
Bluetooth: Bluetooth 5.3/2.1 + EDR Class 1
WWAN Radio (CK62X10 Only)4:
GSM: 850,900, 1800, 1900MHz;
WCDMA: B1/B2/B4/B5/B6/B8/B19
TDD-LTE: B34/38/B39/B40/B41/B42/B43
FDD-LTE: B1/B2/B3/B4/B5/B7/ B8/B12/B13/B17/B19/B20/B25/B26/B28/
B66
5G NR SA: n1/n2/n3/n5/n7/n8/n20/n25/n26/n28/n38/n40/n41/n66/n77/n78
5G NR NSA: n40/n41/n77/n78
GPS (CK62X10 Only) Supported
Protocols: Simultaneous receiver support for dual band (L1 + L5) GPS, AGPS,GLONASS, Galileo and BeiDou

ACCESSORIES
Apart from what it is in the box such as CK62 terminal,hand strap, battery and USB cable, the following accessories are part of our offering.

Scan Handle
Home Base: charges one terminal and one battery
Quad Bay Charging Base
Quad Bay Battery Charger
16 Bay Battery Charger
Universal Dock Cup: uses with Honeywell universal dock for power charging only
Universal Dock: for power charging only
Standard Battery Pack
Hand Strap
Screen Film
Power Adaptor
