DESCRIPTION
Dimensions:
Horizontal: 54.5*52.5*29mm
Vertical: 73.2*52.5*29mm
Weight (device only):
Horizontal: 210g
Vertical: 265g
Housing Material: Zinc alloy
Decoding Performance:
1D bar code: PDF417
2D codes: QR Code, Datamatrix, Maxicode, Aztec

IMAGER
Imager: 838x640,CMOS chip, Global shutter
Imaging Speed: 60 fps
Available Models: 3 versions for different
work distance and FOV: HD, SR and ER
Learning Button: Includes learning button for quick setting
Aiming Device:
0 – Laser indicator;
90 – LED indicator
Dispersed Input: 2*photoelectric dispersed input; definition can be programed
Dispersed Output: 2*photoelectric dispersed output; definition can be programed
Status Output: Five-status LED, buzzer
Power: Standard 10VDC-30VDC
Power Consumption: Max 5W
Communication: RS232, RS485 and Ethernet ports
Network mode: Master/Slave

TEMPERATURE
Operating Temperature: 0ºC to 50ºC
Storage Temperature: -20ºC to 70ºC

SYSTEM ARCHITECTURE
IP Rating: IP65
Operating System: Windows XP, Vista, Windows 7,10Paragraph
Style = Table: Title

TYPICAL PERFORMANCE FOR HD, SR AND ER MODELS*

* Can be influenced by barcode quality and environmental conditions
