Honeywell PD45S PD45 barcode printer ราคาพิเศษ

เครื่องพิมพ์บาร์โค้ดสติกเกอร์ ฮันนี่เวลล์ PD45S PD45

เครื่องพิมพ์บาร์โค้ดสติกเกอร์  Honeywell PD45S PD45

Honeywell PD45 Barcode Printer เป็นเครื่องพิมพ์สติกเกอร์ เกรดอุตสาหกรรม ที่ได้รับการออกแบบให้โครงสร้างประกอบไปด้วยโลหะ ทำให้ตัวเครื่องพิมพ์บาร์โค้ดมีความทนทาน กะทัดรัด และเพรียวบาง เหมาะสำหรับการใช้งานที่หลากหลาย

Honeywell PD45S Barcode Printer ที่ทำงานบนหน่วยประมวลผล แบบ Arm Cortex-A7 / 800Mhz หน่วยความจำ 128MฺB และ DDR3 SDRAM ขนาด 128MB ซึ่งรองรับงานพิมพ์ ทั้งโหมดการพิมพ์ถ่ายเทความร้อน ( Thermal transfer ) และ การถ่ายเทความร้อนโดยตรง ( Direct transfer ) รวมถึงเทคโนโลยีเซ็นเซอร์ คู่ที่ได้รับการจดสิทธิบัตรของ Honeywell รองรับฟังก์ชั่นการกำหนดตำแหน่งแบบไดนามิกที่รองรับความสูงของฉลากสติกเกอร์ ขั้นต่ำ 5 มม. และความแม่นยำ ของตำแหน่งแนวตั้ง 0.5 มม. (PD45S) และ 0.75 มม. (Honeywell PD 45) แถบแรงดันแบบปรับได้สองชุดและแถบกำหนดแนวสื่อแบบคู่ช่วยให้ป้อนกระดาษได้อย่างแม่นยำ และช่วยหลีกเลี่ยงรอยยับของผ้าหมึกและสิ่งสกปรกในการพิมพ์

เครื่องพิมพ์ Honeywell PD 45S มาพร้อมกับหน้าจอ LCD สีแบบสัมผัส ขนาด 3.5" และ LCD ปุ่มกด 2.36"  และ Honeywell PD45 ที่มาพร้อมจอ LCD พร้อมปุ่มกดขนาด 2.36. รวมถึงหัวพิมพ์ที่สามารถ ถอดเปลี่ยนได้ง่าย ทำให้สามารถพิมพ์งานได้ต่อเนื่อง นอกจากนี้ Honeywell PD45 และ Honeywell PD45S รองรับภาษาคำสั่งเครื่องพิมพ์หลายภาษา เช่น FP/DP/IPL/ZPL/DPL  และการเชื่อมต่อที่หลากหลาย เหมาะสำหรับโรงงาน โกดัง หรือ งานขนส่งสินค้า

Part no  PD45S0C0010000200 PD45S0C, color LCD, Direct Thermal and Thermal Transfer printer, Ethernet, 203dpi, no power cord, ROW

*หมายเหตุ คุณสมบัติเครื่องอาจมีการเปลี่ยนได้ทั้งนี้กรุณาติดต่อทางบริษัทฯ เพื่อความถูกต้องต่อไป*

คุณสมบัติหลัก Main specification Honeywell PD45S PD45

GENERAL SPECIFICATION
Product models:
PD4500C: 2.36” keyed LCD
PD4500B: LED, Feed button
PD45S0F: 3.5” color touch control LCD
PD45S0C: 2.36” keyed LCD
Printing modes:
Direct thermal and thermal transfer Printing
Processors:
Arm Cortex®-A7, 800MHz
128 MB flash memory
128 MB DDR3 SDRAM
Multi-GB USB storage device (FAT16/FAT32) Built-in real-time clock

PRINT SPECIFICATIONS
Printing resolution:
203 dpi: 8 dots/mm
300 dpi: 11.8 dots/mm
Printing speed:
203 dpi: 50 - 200mm/s (2-8ips) (pd45)
300 dpi: 50 - 100mm/s (2-4ips) (pd45)
203 dpi:
50 - 250 mm/s (2-10 ips) (pd45s)
300 dpi:
50 - 200 mm/s (2-8 ips) (pd45s)
Maximum width:
203 dpi: 108 mm (4.25 inches)
300 dpi: 105.7 mm (4.16 inches)
Maximum Continuous Print Length:
203 dpi: 4.8 m (15.75 inches)
300 dpi: 2.2 m (7.22 inches)

MECHANICAL
PD4500C/PD4500B
Dimensions (L x H x W):
L: 438 mm x 270 mm x 249 mm
(17.24 in x 10.63 in x 9.80 in)
Weight: 9.25Kg (20.39lbs)
PD45S0F/PD45S0C
Dimensions (L x H x W):
L: 438 mm x 270 mm x 249 mm
(17.24 in x 10.63 in x 9.80 in)
Weight:
PD45S0F: 9.34Kg (20.59lbs)
PD45S0C: 9.25Kg (20.39lbs)

OPTIONS AND ACCESSORIES (PD45)
• Wireless network interface card (PD4500C only)
• Cutter (PD4500C only)

OPTIONS AND ACCESSORIES (PD45S)
• Wireless network interface card (optional)
• Parallel interface card
• Labeling machine interface card
• Industrial GPIO interface card
• Peeling and rewind assembly
• Cutter

RIBBON SPECIFICATIONS
Ribbon supporting:
Inner carbon or outer carbon
Maximum roll diameter:
80 mm (3.15 inches),about 450 m (1,476 feet)
Roll core ID: 25.4 mm (1 inch)
Max. /Min. Width (ribbon and roll core):
110/51 mm (4.33/2.0 inches)
Type:
Wax base, mixed base and resin base
Honeywell’s genuine media:
sps.honeywell.com/us/en/products/productivity/printer-supplies

MEDIA SPECIFICATIONS
Non-continuous label paper, black label paper, tag paper, guide hole paper, notch paper or continuous label paper
Maximum/minimum width (label and liner): 114/20 mm (4.5/0.79 in)
Minimum label length:
Paper tearing mode: 5.0 mm (0.197 inches)
Cutter Mode: 38.0mm (1.5 inches)
Self-peeling mode: 12.7 mm (0.5 inches) (PD45S)
Thickness (label and liner):
3 mil to 8.82 mil (0.076mm to 0.224mm) (PD45)
3 mil to 10 mil (0.076mm to 0.255mm) (PD45S)
Configuration:
External roll paper or folding paper
Maximum diameter of label roll:
203.2 mm (8.0 inches)
Label roll core:
76 mm (3.0 inches)/25.4mm (1.0 inches)

PRINT INTERFACES
Standard:
• USB 2.0 host interface
• USB 2.0 device interface
• Ethernet interface, transmission rate: 10/100 Mbps (PD4500C only)
• RS-232, transmission rate up to 115.2 KB/s (PD4500C only)
It supports the following serial port protocols:
• Fingerprint/Direct Protocol: XON/XOFF, ENQ/ACK, RTS/CTS
• IPL: XON/XOFF, Honeywell Std. Protocol
Optional: (PD45)
• WIFI(PD4500C only): IEEE 802.11a/b/g/n/ac, WFA certified, Static WEP (64 bit and 128 bit), Dynamic
WEP (TLS, TTLS, PEAP, LEAP, EAPFAST),
WPA (THIP/CCKM Personal and Enterprise, WPA2 (AES-CCMP/CCKM Personal and Enterprise)
• Dual serial ports(PD4500C only): RS-232, RS-422 and RS-485, and 20 mA current loop, GPIO card
Optional: (PD45S)
• WIFI: IEEE 802.11 a/b/g/n/ac, Static WEP (64 bit and 128 bit), Dynamic WEP (TLS, TTLS, PEAP, LEAP, EAPFAST), WPA (THIP/CCKM Personal
and Enterprise, WPA2 (AES-CCMP/ CCKM Personal and Enterprise)
• Parallel port: IEEE 1284
• Industrial interface: 8-bit INPUT/ output, 4 analog signal relays and 1 RS-232/422/485 port
• Dual serial ports: RS-232, RS-422 and RS-485, and 20 mA current loop, GPIO card

OPERATING ENVIRONMENT
Operating temperature:
+5°C to +40°C (+41°F to +104°F)
Storage temperature:
-20°C to +70°C (-4°F to +158°F)
Humidity:
20% to 85%, non-condensing
APPROVALS
CB\ CE; for more compliance information, please contact your local sales representative.

BARCODES/FONTS/GRAPHICS
Barcodes:
Supporting all main 1D and 2D symbols
Supporting standards:
UPC/EAN Shipping Container, UCC/EAN
128, Serial Shipping Container, MH10.8 Shipping Label, AIAG (shipping parts label, OGMARS, POSTNET, HIBCC, ISBT 128, GM1724, UPS Shipping Label and
Global Transport Label
Font:
Monotype font engine; non-Latin fonts can be supported through WTLE, and customers can also download (Truetype) fonts by themselves.
Graphics:
It supports PCX, PNG, GIF and BMP file formats. Other formats can be supported
by Label Generation Tools.

SOFTWARE
Printer command languages:
Fingerprint (FP), Direct Protocol (DP), IPL, ZSim2 (ZPL-II), DPL; XML can be enabled for SAP AII and Oracle WMS;
Application programs /Driver programs:
InterDriver Windows printer drive and one-key installation driver, CUPS driver for Linux, program packages for Honeywell device type for SAP and Honeywell label design and printing

SMART PRINTING languages:
Honeywell’s special C# languages for printers: Smart Printing Developer Resource Kit; write application in the development environment compatible with .NET.
Configuration and equipment management support:
Printset supports Windows to configure printers; the mature Web interface is
used for configuration and one-to-one management
SAP, Oracle, Linux and Windows are trademarks or registered trademarks of their respective owners.

USER INTERFACE LANGUAGES
Color CNC LCD and WEB interface:
English, Italian, French, Spanish,
Portuguese, German, Russian, Traditional
Chinese, Simplified Chinese, Korean,
Japanese and Thai

POWER SUPPLY
PFC power supply with the rated power
of 100W AC voltage: 100V AC to 240V AC,
50Hz to 60Hz
