SPECIFICATIONS
Physical Characteristics
Dimensions
8 inch: 8.42 in. L x 5.32 in. H x 0.45 in. D
213.9 mm L x 134.8 mm H x 11.4 mm D
10 inch: 10.15 in. L x 6.41 in. H x 0.45 in. D
257.9 mm L x 162.9 mm H x 11.4 mm D
Weight
8 inch: 1.07 lbs/485 g
10 inch: 1.52 lbs/690 g
Display
8 inch/20.3 cm: 500 nits, color WXGA 1280x800
10.1 inch/25.7 cm: 500 nits, color WUXGA
1920x1200; Corning® Gorilla® Glass
Imager Window : Corning Gorilla Glass
Touch Panel : Capacitive multi-touch
Expansion Slot : Integrated connector to easily add accessories
Connectivity
Docking connector (charge and data)
USB-C side port (tablet charging and data only)
SIM Slots : 1 nano SIM
Interface Ports : Expansion connector for Zebra accessories
Notifications : Audible tone; multi-color LEDs; vibration
Keyboard Options : Virtual, Bluetooth, USB
Audio : Stereo speakers; two microphones; audio headset support via USB-C port or Bluetooth
Buttons : Volume up/down; power on/off; barcode scanner; programmable buttons
Performance Characteristics
CPU : Qualcomm SnapdragonTM SM6375
Octa-Core (8): 2.2 GHz (2) and 1.8 GHz (6)
Operating System : Upgradeable to Android 14
Memory
Standard: 4 GB LPDDR4X SDRAM/64 GB UFS Flash
Premium: 8 GB RAM/128 GB
General Certifications
EPEAT Bronze7, Energy Star
User Environment
Operating Temp. : -4°F to 122°F/-20°C to 50°C
Storage Temp. : -40°F to 158°F/-40°C to 70°C
Humidity : 5% to 95% non-condensing
Drop Specifications
Standard:
4 ft. / 1.2 m to concrete per MIL-STD-810H
With optional rugged frame:
5.1 ft. / 1.55 m per MIL-STD-810H
Sealing : IP65
Vibration :
Sine: 4 g’s PK(5 Hz to 2 kHz)
Random: 6 g RMS (20 Hz to 2 kHz)
60 minute duration per axis, 3 axis
Electrostatic Discharge (ESD) : +/- 15 kV air discharge; +/- 8 kV contact; +/- 8 kV indirect
Power
Battery User Profile :
Ample power for a full shift; continuous operation is enabled with the secondary optional battery
Battery :
Battery User Profile :
Ample power for a full shift; continuous operation is enabled with the secondary optional battery
Battery :
8 inch: 6100 mAh 3.87 V rechargeable Li-Ion Polymer; user replaceable (23.61 Wh)
10 inch: 7600 mAh 3.87 V rechargeable Li-Ion Polymer; user replaceable (29.41 Wh)
Optional hot swappable 3400 mAh 7.6 V (25.84 Wh)
|
Interactive Sensor Technology (IST)
Ambient Light Sensor : Automatically adjusts display brightness and display backlight
Magnetometer : eCompass automatically detects direction and orientation
Motion Sensor : 3-axis gyroscope; 3-axis accelerometer
Data Capture
Scanning : SE4100 1D/2D Scan Engine; SE4710 1D/2D Scan Engine; SE55 1D/2D Advanced Range Scan Engine with IntelliFocus technology (Premium)
Rear Camera : Image capture: 13 MP auto-focus camera with user controllable LED flash
Front Camera : 5 MP
Wireless Communications
Wi-Fi (WLAN) :
IEEE 802.11 a/b/g/n/ac/d/h/i/r/k/v/w/mc/ax
2x2 MU-MIMO; Wi-Fi® certified; IPv4, IPv6 (Wi-Fi 6)
Cellular (ET45 Only) (WWAN Data Only) :
5G (North America, Rest of World)
Global LTE (North America, Rest of World)
3G, 2G (Rest of World)
North America 5G, LTE: AT&T and Verizon
Bluetooth (WPAN) : Bluetooth v5.1 / 2.1+EDR Class 2 (Bluetooth LE)
GPS (ET45 Only) : GNSS supports GPS, Galileo, Beidou, Glonass. Dual Band (L1+L5)
NFC :
Reader/Writer: ISO 14443 Type A and B, ECP, MIFARE, FeliCa®, ISO 15693, NFC Forum Tag Types 1 to 5; Host Card Emulation
Support for Apple Pay VAS8 / Google SmartTap8,NFC Forum Certified
Wireless LAN
Data Rates :
5 GHz: 802.11a/n/ac/ax - 20 MHz, 40 MHz, 80 MHz - up to 1201 Mbps
2.4 GHz: 802.11b/g/n/ax - 20 MHz - up to 286.8 Mbps
Operating Channels :
Channel 1-13 (2412-2472 MHz) : 1,2,3,4,5,6,7,8,9,10,11,12,13
Channel 36-165 (5180-5825 MHz) : 36,40,44,48,52,56,60,64,100,104,108,112,116, 120,124,128,132,136,140,144,149,153,157,161,165
Channel Bandwidth : 20, 40, 80 MHz
Actual operating channels/frequencies and bandwidths depend upon regulatory rules and certification agency
Security and Encryption :
WEP (40 or 104 bit); WPA/WPA2 Personal (TKIP, and AES); WPA3 Personal (SAE); WPA/WPA2 Enterprise (TKIP and AES); WPA3 Enterprise (AES) — EAP-TTLS (PAP, MSCHAP, MSCHAPv2), EAP-TLS,PEAPv0-MSCHAPv2, PEAPv1-EAP-GTC, LEAP and EAP-PWD; WPA3 Enterprise 192-bit mode (GCMP256) - EAP-TLS; Enhanced Open (OWE)
Certifications :
Wi-Fi Alliance Certifications:
Wi-Fi CERTIFIED n; Wi-Fi CERTIFIED ac; Wi-Fi CERTIFIED 6 ; Wi-Fi Enhanced Open; WPA2-Personal; WPA2-Enterprise; WPA3-Personal; WPA3-Enterprise (includes 192-bit mode); Protected Management Frames; Wi-Fi Agile Multiband; WMM; Wi-Fi Direct
Fast Roam : PMKID caching; 802.11r (Over-the-Air); OKC
Wireless PAN :
Bluetooth : Bluetooth v5.1 Class 2, Bluetooth Low Energy (BLE)
|
