Zebra ZC100 Card Printer

เครื่องพิมพ์บัตรพลาสติก ZEBRA ZC100

CARD PRINTER ZC100

PRINT TECHNOLOGY : Direct-to-Card Printer

PRINT CAPABILITIES : Single-sided

PRINT SPEED
Color
- 150 cph
Mono - 700 cph

MAX. IMAGES PER RIBBON ROLL : Colour - 200 , Mono - 2000

COMMUNICATIONS INTERFACE

Standard – USB 2.0
Optional – Built-in 10/100 Ethernet; 802.11ac MFi

OPTIONS

Magnetic stripe encoder        Third party contactless encoder integration kit

*หมายเหตุ คุณสมบัติเครื่องอาจมีการเปลี่ยนได้ทั้งนี้กรุณาติดต่อทางบริษัทฯ เพื่อความถูกต้องต่อไป*

คุณสมบัติหลัก Main specification Card Printer  ZC100

ZC100 CARD PRINTER SPECIFICATIONS

Standard Features
• 300 dpi (11.8 dots/mm) print resolution
• 2 GB flash memory
• Image size: 1006 x 640 pixels
• Auto calibration of ribbon
• USB 2.0 connectivity
• 100 card capacity auto-adjusting input hopper (30 mil)
• 100 card capacity output hopper (30 mil)
• Manual card feeding capability with LED bezel
• 3 Tricolor printer status indicator lights
• Kensington® secure lock slot
• Printer host authentication and data encryption
• Print Touch NFC tag and Quick Help QR code for online printer help and documentation access
• Two-year unlimited warranty on printer and printhead

Printing Specifications

• Dye-sublimation thermal transfer direct to card print method
• Full-color or monochrome printing
• Single-sided printing
• Edge-to-edge printing on standard CR-80 media
Printing throughput (cards per hour) based on batch printing with USB connectivity. Times may vary depending on the computer configuration.
YMCKO: Single-Sided: 150 cph
Monochrome: Single-Sided: 700 cph

Media Specifications

Supplies Specifications:
NOTE: The ZC100 printer is designed to work only with Zebra genuine ribbons. Ribbons are included in a simple-to-load cartridge.

Ribbon Description : Cartridge Image Count
YMCKO* : 200
1/2 YMCKO* : 400
Black Monochrome* : 2000
Black Monochrome : 1500
White Monochrome* : 1500
White Monochrome : 1500
Red Monochrome : 1500
Blue Monochrome : 1500
Gold Monochrome : 1500
Silver Monochrome : 1500
*Zebra intelligent technology automatically detects and authenticates ribbon
• Cleaning roller is included with each ribbon
• Two available cleaning kit options: your choice of two (2) or five (5) isopropyl alcohol cleaning cards (1,000 images/card)
Card Compatibility:
NOTE: For optimum print quality and printer performance, use of Genuine Zebra supplies is recommended.
• Card Thickness: 10-40 mil*
• Card Size: CR80 ISO 7810 ID-1 format, CR79*
• Card Material: PVC and PVC composite
• Adhesive back and writable back cards
• Transparent cards*
*Note: Spot color or monochrome printing recommended only on >20 mil thick cards, CR79 cards, and transparent cards.

Operating Characteristics

Operating Temp. : 59º F to 95º F/15º C to 35º C

Operating Humidity :20% to 80% non-condensing

Media Storage
— Temperature: 41º F to 77º F/5º C to 25º C
— Humidity: 35% to 65% non-condensing
Electrical
• Auto-switching single-phase AC power
• Operating range: 90-132VAC and 190-264VAC RMS
• Frequency range: 47-63 Hz
• FCC Class A

Physical Characteristics

Dimensions
10.2 in. H x 6.2 in. W x 15.1 in. D
258 mm H x 157 mm W x 383 mm D
Weight 8.6 lbs (3.9 kg)

Communications and Interface Capabilities
USB 2.0 : Standard
Built-In 10/100 Ethernet  : Optional
802.11ac  : Optional

Encoding Options and Specifications
• Magnetic stripe encoder — ISO 7811 (new and pre-encoded; tracks 1, 2, and 3; high and low coercivity; stripe down; 30 mil cards only) *
• Third party contactless encoder integration kit (ZIP Pocket)*
*Field upgradeable options

Printer Drivers
Microsoft Windows Certified :
Windows Server 2008 (32 and 64 bit),
Windows 7 (32 bit and 64 bit)
Windows 8 and Windows 8.1
(32 bit and 64 bit compatible)
Windows Server 2012 (64 bit)
Windows 10 (32 bit and 64 bit)
Windows Server 2016
Windows drivers include:
Color coded printer status indicators for the operator
• Black panel extraction and controls for specialty ribbon panels with image preview
• Configuration utility to limit access by operators to change image quality and printer settings
• Advanced printer configuration, security settings and diagnostics capab

Linux : Ubuntu 16..X (64 Bit)
Apple : MAC OS X 10.13.X (64 bit)

Additional Optional Features

Lockable enclosure (field upgradeable option)

Multiplatform Software Development Kit (SDK)

• Windows C#/.Net and Java Printer Software Development Kit (SDK)
• One SDK supports Android, Java and Windows environments
• Easily build card-printing apps with complete control over print functionality from Windows, Linux, Mac OS and Android environments
• Enable card printing from Android mobile devices
• Incorporate encryption and host authentication (Windows only)
• Includes documentation and source code examples

CardStudio

A simple-to-learn and feature-rich card design software that makes it easy to design loyalty cards, gift cards, ID cards and more.

Print Touch

With a single tap, you can use Android-based mobile devices to access how-to and troubleshooting information to help keep printers up, running and available.

Printer Profile Manager Enterprise (PPME)

PPME facilitates the centralized control and management of a large number of Card printers via an intuitive Web interface. This application makes it easy to navigate through all the Card Printer settings and quickly create your printer profiles with just a handful of ‘clicks’. Update and manage networked Enterprise Zebra Link-OS printers from a single console automatically with a direct encrypted connection to protect sensitive data.
