PHYSICAL CHARACTERISTICS Mobile Computer Zebra MC3200

Dimensions
Straight Shooter:
7.49 in. L x 3.22 in. W x 1.78 in. D
190.4 mm L x 81.9 mm W x 45.2 mm D
At grip: 2.40 in. W x 1.35 in. D
60.9 mm W x 34.2 mm D
Rotating Turret:
8.37 in. L x 3.22 in. W x 1.57 in. D
212.6 mm L x 81.9 mm W x 40.0 mm D
At grip: 2.40 in. W x 1.35 in. D
60.9 mm W x 34.2 mm D
Gun:
7.59 in. L x 3.18 in. W x 6.5 in. D
192.7 mm L x 80.8 mm W x 166 mm D

Weight (including strap, stylus, and battery)
Straight Shooter:  12.88 oz./365 g
Rotating Turret:  13.13 oz./372 g (with standard battery)
Gun:  18.0 oz./509 g (with extended battery)
Display 3.0 in. color (TFT) (320 x 320) display
Touch Panel Chemically strengthened glass, resistive touch
Backlight   LED Backlight
Keypad Options  28-key Numeric, 38-key Shifted Alpha, 48-key Alpha-Numeric
Expansion Slot   User accessible Micro SD slot; (supports up to 32 GB microSDHC)
Notifications  LEDs, audio
Audio Speaker, microphone and headset connector   (2.5 mm jack)

PERFORMANCE CHARACTERISTICS

CPU Dual core 800 MHz OMAP4 Processor (Standard) or Dual core 1 GHz  OMAP4 processor (Premium)
Operating  System  Choice of Windows Embedded Compact 7.0 (Standard or Premium) or Android 4.1 (Premium)
Memory 512 MB RAM/2 GB Flash (Standard) , 1 GB RAM/4 GB Flash (Premium)
Power PowerPrecision Li-Ion batteries
Two options: High Capacity 4800 mAh or Standard Capacity 2740 mAh (not available on gun form factor)

USER ENVIRONMENT

Operating Temp.  -4° F to 122° F/-20° C to 50° C
Storage Temp.  -40° F to 158° F/-40° C to 70° C
Battery Charging  Temp.  32° F to 104° F/0° C to 40° C
Humidity 10 - 95% non-condensing
Sealing   IP54 per IEC specification
Drop Specs Multiple 4 ft./1.2 m drops to concrete across the operating temperature range, multiple 5 ft./1.5 m drops to concrete at ambient  temperature 73° F/23° C; meets and exceeds MIL-STD 810G
Tumble Specs  500 1.64 ft./0.5 m tumbles (1,000 drops) at room temperature per IEC 68-2-32 tumble specifications
ESD EN61000-4-2; ± 20kV Air discharge, ± 10kV direct discharge, ± 10kV  indirect discharge

Scanning
1D Laser(1): SE965 Standard Range with Adaptive Scanning (all  models)
1D/2D Imager: SE4750-SR, 4750-MR (Straight Shooter and Gun  models only)

INTERACTIVE SENSOR TECHNOLOGY (IST)

Motion-sensor
CE7.0/Premium model: 3-axis accelerometer that enables motion-sensing applications on dynamic screen orientation, power management and free-fall detects; Android: 3-axis accelerometer that detects screen rotation

APPLICATIONS

Included  Applications  Asset Tracker Lite

WIRELESS LAN VOICE AND DATA COMMUNICATIONS

Radio IEEE® 802.11a/b/g/n
Security Security Modes:Legacy(3), WPA and WPA2 (Personal or Enterprise);802.1X
Encryption:WEP40/WAP104, TKIP and AES
Authentication:TLS; TTLS (CHAP(3), MSCHAP, MSCHAPv2, PAP or MD5(3)); PEAP (TLS(3), MSCHAPv2, GTC); LEAP; FAST (TLS(3), MSCHAPv2, GTC)
Other: Wi-Fi CCXv4 certified; supports IPv6; FIPS 140-2 certified  (Android), Q4-2014 (WinCE)
Antenna Internal antenna w/diversity
Data Rate 802.11a/g: up to 54 Mbps; 802.11b: up to 11 Mbps; 802.11n: up to 65 Mbps (72 Mbps w/SGI)
Operating Channels
Chan 36-165 (5180 - 5825 MHz), Chan 1-13 (2412-2472 MHz); Actual operating channels/frequencies depend on regulatory rules and certification agency

WIRELESS PAN DATA AND VOICE COMMUNICATIONS

Bluetooth Class II, v2.1 with Enhanced Data Rate (EDR); integrated antenna

VOICE AND AUDIO

PTT (client included); high-quality speakerphone; wireless (Bluetooth) and wired headset support; PTT will support headset and speakerphone mode.

NETWORK COMMUNICATIONS
