Zebra PS20 Mobile Computer

คอมพิวเตอร์พกพา (Handheld Computer) ซีบร้า PS20

คอมพิวเตอร์มือถือ (Mobile computer) Zebra PS20

Zebra PS20 Mobile Computer เครื่องสแกนมือถือ  ที่ช่วยในการเพิ่มมูลค่าในการขายสินค้าร้านค้าตามร้านค้า มาร์เก็ต ตัวเครื่อง Mobile เป็นเครื่องที่มีOS เป็น Android หน้าจอสัมผัสขั้นสูง มองเห็นได้ง่ายทุกสภาพแสง และด้วยเทคโนโลยีการสแกนขั้นสูง ของการอ่านบาร์โค้ดไม่ว่าจะเป็น 1D และ 2D รวมถึงรองรับการอ่าน Digimarcการระบุตำแหน่งที่ตั้ง นอกจากนี้กรณีที่มีการใช้อุปกรณ์ MC18 เดิมมาก่อนและมีการใช้อุปกรณ์เสริม ของMC18 เครื่อง Zebra PS20 ก็ยังสามารถใช้งาน แทนกันได้โดยไม่ต้องเปลี่ยนตัวอุปกรณ์  และด้วย App ใหม่ของ Zebra ถึง 4 App ทั้ง

-           WorryFree WiFi ที่ช่วยให้การเชื่อมต่อ WiFi ที่ดีที่สุดผ่านเทคโนโลยีไร้สายขั้นสูง

-           PowerPrecision Console การระบุและถอดแบตเตอรี่คอมพิวเตอร์มือถือที่ใช้งานมานาน

-          Analytics ใหม่ของ LifeGuard นำการปฏิวัติ การควบคุมแบบ end-to-end และความเรียบง่ายมาสู่กระบวนการอัปเดตระบบปฏิบัติการ และโหมดที่ จำกัด ใหม่ของ

StageNow ช่วยให้คุณสามารถเลือกบริการมือถือของ Google ที่คุณต้องการเปิดใช้งาน



โดยทางบริษัทได้ทำการจัดจำหน่าย สินค้าเครื่องพิมพ์บาร์โค้ด เครื่องพิมพ์บาร์โค้ด เครื่องอ่านบาร์โค้ด เครื่องพิมพ์ใบเสร็จขนาดพกพา คอมพิวเตอร์ขนาดพกพา เครื่องพิมพ์บัตร และอุปกรณ์การพิมพ์ ทั้งสติกเกอร์ม้วนสำหรับการพิมพ์บาร์โค้ด ผ้าหมึกสำหรับเครื่องพิมพ์สติกเกอร์ ที่มีคุณภาพราคาที่เหมาะสม



*หมายเหตุ คุณสมบัติเครื่องอาจมีการเปลี่ยนได้ทั้งนี้กรุณาติดต่อทางบริษัทฯ เพื่อความถูกต้องต่อไป*

คุณสมบัติอย่างย่อ Mobile computer Zebra PS20


ระบบการอ่าน : 1D , 2D

หน่วยประมวลผล : Qualcomm Snapdragon™ 660 octa-core, 2.2 GHz

หน่วยความจำ : 4GB RAM/16GB Flash

หน้าจอ : 4 นิ้ว

รองรับการเชื่อมต่อ : WLan, Bluetooth

ระบบปฏิบัติการ : Android 10; upgradeable through Android 12*

กันกระแทก : Multiple 4 ft./1.2 m drops

การเชื่อมต่อ : USB

คุณสมบัติหลัก Main specification Zebra Mobile Computer  PS20

Physical Characteristics

Dimensions
2.95 in. H x 8.58 in. L x 3.09 in. W
7.50 cm H x 21.80 cm L x 7.86 cm
Weight : 290g
Display  : 4.0 inch capacitive; WVGA; color
Touch Panel :  Corning Gorilla Glass touch panel with air gap
Imager Window : Corning Gorilla Glass
Interface/Communications :  USB 2.0 Client Cable for device maintenance
Voice  : Push-to-Talk (PTT) voice support via internal speaker; Zebra Workforce Connect PTT Pro (optional)
Audio  :  Speaker; One (1) microphone (Plus configuration)
Buttons  : 1 dedicated scan button



Performance Characteristics

Processor  :  Qualcomm Snapdragon™ 660 octa-core, 2.2 GHz
Operating System  :  Android 10; upgradeable through A11/ R²
Memory  :  Base and Plus Configurations: 4GB RAM/16GB Flash
Power   :  PowerPrecision+ 3500 mAh capacity Li Ion rechargable battery
Security   : Verified Boot; Secure Boot



User Environment

Operating Temp.  :  14° F to 122° F/-10° C to 50° C
Storage Temp.  :  -4° F to 158° F/-20° C to 70° C
Humidity  :  Relative Humidity 5% to 95% non-condensing
Drop Specification  :  Multiple 4 ft./1.2 m drops to concrete over the entire operating temperature range
Tumble Specification  :  1,000 1.64 ft./0.5 m tumbles at room temperature
Vibration  :  2g peak, 5 Hz to 2 kHz, 1 hour duration per axis
Thermal Shock  :  -4° to 158° F/-20° to 70° C
Electrostatic Discharge (ESD)  :  (+/-15kV) air, (+/-8kV) contact discharge



Data Capture

Scanning
Base model  :   SE2100 1D/2D imager
Plus model  :   SE4710 1D/2D imager + Digimarc support

Light Source
Base model: White LED Illumination
Plus model: Red LED Illumination with LED dot aim pattern

Camera — Front Facing  :  Plus model only: 5 MP fixed focus



Interactive Sensor Technology

Plus configurations only: 3-axis accelerometer, gyroscope, scanning proximity sensor

WLAN

Radio
IEEE 802.11 a/b/g/n/ac/d/h/i/r/k/v3/w; Wi-Fi™ certified; IPv4, IPv6, 2x2 MU-MIMO

Data Rates
5GHz: 802.11a/n/ac — up to 866.7 Mbps
2.4GHz: 802.11b/g/n — up to 300 Mbps

Operating Channels (depending on Regulatory)
Channel 1-13 (2412-2472 MHz);
Channel 36-165 (5180-5825 MHz)
Channel Bandwidth: 20, 40, 80 MHz

Actual operating channels/ frequencies and bandwidths depend on regulatory rules and certification agency

Security and Encryption
WEP (40 or 104 bit); WPA/WPA2 Personal (TKIP, and AES); WPA/WPA2 Enterprise (TKIP and AES)

— EAP-TTLS (PAP, MSCHAP, MSCHAPv2), EAP-TLS, PEAPv0-MSCHAPv2, PEAPv1-EAP-GTC and LEAP. EAP-PWD

Certifications    WFA (802.11n, WMM-PS, 801.11ac, PMF)

Fast Roam          PMKID caching; Cisco CCKM; 802.11r; OKC



WPAN

Class 2, Bluetooth v5.0, Bluetooth Low Energy (BLE)
